Basic Info.
Model NO.
mc-500w
Charger Application
Laptop, Camera, Standard Battery
Nominal Voltage
12V
Charger Style
USB Charger
Compatible Battery Type
18650
Certification
GOST-R, PSE, RoHS, TUV, CB, CE
Recyclable
Recyclable
Wireless Charger
15W
Weight (Including Accessories)
9kg
PV Input
12~100V 400W Max Charger
Display
with Display
Charging Type
Electric, Solar, Car
LED Lighting
LED Lighting
AC Input
230W
Useage
Oudoor,Camping,Car
Car Output
DC 12V/8A(120W Max)
USB Output
QC3.0/18W
Carrying Way
Universal Split
Color
Red/Orange/Yellow/Green/Cyan/Blue/Purple
AC Output
AC 220V 50Hz/AC110 60Hz 330W Pure Sine Wave
Package
Standard Export Package
Transport Package
Packing by Carton
Specification
295*202*241mm
Trademark
OEM/ODM
Origin
China
HS Code
8507600090
Production Capacity
100000
Packaging & Delivery
Package Size
35.00cm * 25.00cm * 30.00cm
Package Gross Weight
15.000kg
Product Description
Specification
| No | Items | Parameter | Standard |
| 1 | Model | MC500 | |
| 2 | Battery type | Li-ion 18650 cell | 3.7V |
| 3 | Rated Capacity | 140400mAh | |
| 4 | Output | USB output port | 3*QC 3.0 USB(5V/3A ) |
| USB output port working time | >30h | ||
| DC output port | 14V4A/14V8A | ||
| DC output port working time | >8h | ||
| AC output port | 110V/500W Pure Sine Wave | ||
| Type-C | 5V/3A | ||
| Car output port working time | >2.5h | ||
| cigarette lighter | 14V/8A | ||
| Wireless Charging | 10W | ||
| LED | 3W | ||
| Reverse charging protection | Yes | ||
| 5 | Charging | Charging voltage | 12-28V |
| Charging Current | 10A | ||
| Charging Time | About 10h | ||
| 6 | Self-consumption | On working | 200mA |
| On standby | 5mA | ||
| 7 | Dimensions | L*W*H | 280*200*200mm |
| 8 | Weight | Weight(Net weight) | 4.8kg |
| Weight(with accessories) | 5.8kg | ||
| 9 | Range of Working Temperature | Charging | 10ºC~40ºC |
| Discharging | 0ºC~75ºC | ||
| 10 | Range of Storage Temperature | Less than 1 year | -20ºC~+25ºC |
| Less than 3 months | -20ºC~+45ºC | ||
| Less than 1 month | -20ºC~+60ºC |
Package including
| No | Name | Model | Unit | Quantity |
| 1 | portable power station | MC500 | pcs | 1 |
| 2 | Adapter | 25V 4A | pcs | 1 |
| 3 | Solar charging wire | pcs | 1 | |
| 4 | Car charger line | pcs | 1 | |
| 5 | User manual | pcs |
Customized logo
we can do your own logo on power station
Why choose us?
We are a battery manufacturer with 15 years' experience in rechargeable batteries.Ourcompany has independent R&D and production capabilities in key links, which can
provide customers with professional solutions and services of energy system and
lithium battery. Our products are widely used in lead-acid replacement, household energy
storage system, industry, data center, 5G, UPS, low-speed EV, portable power station and so on.
Performance Test:
1.Standard test conditions
The test product must be a new product that has not been shipped for more than one month and the battery has not been cycle charge and discharge more than 5 times. Unless otherwise specified, the tests in this specification shall be under the following
conditions:Temperature:23ºC±2ºC;
Relative humidity:45%~85%RH; Atmospheric pressure:86kPa~106kPa;
2.Measurement Apparatus
(1)Dimension Measuring Instrument
The dimension measuring shall be implemented by instruments with equal or more precision scale of 0.01mm;
(2)Voltmeter Standard class specified in the national standard or more sensitive class having inner 7 Lithium Battery Expert 15 Years impedance not less than 10kΩ /V
The dimension measuring shall be implemented by instruments with equal or more precision scale of 0.01mm;
(2)Voltmeter Standard class specified in the national standard or more sensitive class having inner 7 Lithium Battery Expert 15 Years impedance not less than 10kΩ /V
(3)Ammeter
Standard class specified in the national standard or more sensitive class. Total external resistance including ammeter and wire is less than 0.01Ω
(4)The resistance test method is the AC impedance method (AC 1kHz LCR)
Standard class specified in the national standard or more sensitive class. Total external resistance including ammeter and wire is less than 0.01Ω
(4)The resistance test method is the AC impedance method (AC 1kHz LCR)
The resistance is not a constant value and varies with temperature and saturation of the state of charge, and related to length and capacity of the cable.
(7)The temperature measuring instrument should not be lower than ±0.5°C;
(5)All testing equipment and measuring instruments must be inspected by the certification institutes;
(6)Battery test system current accuracy should be within ±0.1%, constant pressure accuracy within ±0.5%, timing accuracy within ±0.1%;(7)The temperature measuring instrument should not be lower than ±0.5°C;
Q1: Can we get samples for test?
A: Yes, we can supply samples, and buyer pay for sample cost and shipping cost.
Q2: What is the MOQ ?
A: We can accept < 50pcs for trial order.
Q3: Can you accept OEM and ODM Service?
A: Yes.
Q4: What about the lead time?
A: Sample needs ~2wks , mass production time needs 2wks-4wks.
Q5: How do I track my shipment?
A: After we deliver your goods, we will send you the tracking No. once your goods has been shipped.
