Basic Info.
Model NO.
SM-FG100
Weight
3.55kg
Warranty
1 Year
Peak Power Pm(W)
100W
Open Circuit Voltage Voc(V)
21.6V
Max. Power Voltage Vmp(V)
18.0V
Max. Power Current Imp(a)
5.5A
Short Circuit Current Isc(a)
6.6A
Solar Panel Model & Qty
50W/9V*2PCS Series Connection
Solar Cells Efficiency
22.0%
Folded Size
540*550*3 mm
Unfolded Size
1275*540*1.5 mm
Net Weight
3.53 Kg
Transport Package
Box
Specification
750*620*70mm
Trademark
Sharmeal
Origin
China
HS Code
8507600090
Production Capacity
60000pieces/Year
Product Description
High Quality Charging Home Cheap 100W Solar Panel Portable Power Station For Power Station
1:Solar panels should be placed in direct sunlight and adjusted at an appropriate angle to receive maximum sunlight for power generation.
2:This product can be used to charge portable power station with a rated voltage of DC 12-14V (with built-in solar charging protection function) or battery. But the output electrode of the solar panel cannot be used to directly charge the battery. A solar charging controller is a must to protect the battery from overcharging or prevent the damage to solar panel/battery or any person in case connecting the reverse electrode. If the device is an energy storage integrated machine, it can be connected to the solar charging interface accordingly.
3:The rainwater will not affect normal use. ((Not get the conductive/corrosive liquids such as seawater onto it, as it may cause internal short circuits and prevent normal power generation. If there is contact, rinse it with clean water and dry it.)
4:When connecting the solar controller/energy storage integrated machine, make sure of the correct poles of the interface.
5:Before connecting to the solar controller/battery/energy storage integrated machine, the product specifications/power/current/voltage should be checked, and the limit values should not be exceeded to prevent damage to the equipment.
6:The voltage of this solar charger bag under sunlight does not exceed the safety voltage of human body, but direct contact or short circuit of the device electrode should also be avoided in case any safety hazards.
7:Handle with care when using it, do not drop, press or collide hard, as it may damage the solar cell.
| Model | SM-FG100 | |
| Peak power Pm(W) | 100W | |
| Open circuit voltage Voc(V) | 21.6V | |
| Max. power voltage Vmp(V) | 18.0V | |
| Max. power current Imp(A) | 5.5A | |
| Short circuit current Isc(A) | 6.6A | |
| Solar cells Efficiency | 22.0% | |
| Solar panel model & qty | 50W/9V*2pcs series connection | |
| Folded size | 540*550*3 mm | |
| Unfolded size | 1275*540*1.5 mm | |
| Net weight | 3.53 kg | |
| solar cell | A-grade monocrystalline battery cells | |
| Solar panel Front cover(material) | Clear ETFE Transparent composite materials on the surface of battery cells enhance protection optional | |
| Solar panel backboard(material) | Glass fiber board optional | |
| Output port | 1:direct output line (MC4/DC/Anderson/XT60 interface) optional / customizable | |
| handbag material(Outer surface) | black (waterproof) color/logo customizable, logo can be silk printed | |
| NOCT/Operating temperature limits | Rated operating temperature:48±2ºC /Operating temperature range:-40ºC- +85ºC | |
| Storage temperature limits | -10ºC- +30ºC | |
| Waterproof grade | IP65 | |
| Power/voltage/current temperature coefficient | -0.35%/ºC ;-0.272%/ºC;+0.044%/ºC | |
| Lifespan / Warranty | ≥10 years / 1 year | |
| STC Standard test conditions | irradiance:1000W/m2, temperature:25ºC,AM:1.5 | |
| Other | 25MM Rubber handle black optional | |
| Packing size/weight | 1 pc/ctn, ctn size: 750*620*70mm G.W: 4.32KG/ctn | |
Company Introduction:
Foshan Guanyu Intelligent Technology Co., Ltd was founded in 2018, which is a national high-tech enterprise. Sharmeal is committed to the R&D, manufacturing, and sales of portable power products. Sharmeal has successfully attained the certificates for ISO9001 and ISO14001 quality management systems. In addition to that, most of our battery products are CE, and UN38.3 certified. The product line covers outdoor power storage, portable jump starter, solar panels, etc.
There are more than 400 employees, a production workshop of 10,000 square meters, 2 fully automatic Battery cell production lines, 4 automatic SMT production lines, and 4 energy storage product assembly lines.
All products are purchased with quality liability insurance to provide customers with safe and stable products and services.
Fine quality, timely delivery, consummate service, and competitive prices enable Sharmeal to keep attaining praise from our domestic and foreign clients. We, Sharmeal with the greatest passion and faithfulness, are willing to strive together with our customers to make progress and create a bright future!
1:Solar panels should be placed in direct sunlight and adjusted at an appropriate angle to receive maximum sunlight for power generation.
2:This product can be used to charge portable power station with a rated voltage of DC 12-14V (with built-in solar charging protection function) or battery. But the output electrode of the solar panel cannot be used to directly charge the battery. A solar charging controller is a must to protect the battery from overcharging or prevent the damage to solar panel/battery or any person in case connecting the reverse electrode. If the device is an energy storage integrated machine, it can be connected to the solar charging interface accordingly.
3:The rainwater will not affect normal use. ((Not get the conductive/corrosive liquids such as seawater onto it, as it may cause internal short circuits and prevent normal power generation. If there is contact, rinse it with clean water and dry it.)
4:When connecting the solar controller/energy storage integrated machine, make sure of the correct poles of the interface.
5:Before connecting to the solar controller/battery/energy storage integrated machine, the product specifications/power/current/voltage should be checked, and the limit values should not be exceeded to prevent damage to the equipment.
6:The voltage of this solar charger bag under sunlight does not exceed the safety voltage of human body, but direct contact or short circuit of the device electrode should also be avoided in case any safety hazards.
7:Handle with care when using it, do not drop, press or collide hard, as it may damage the solar cell.
